❖Features
Seamless 16A AC Internal Transfer Switch
AC RCD/Safety Switch with test button
Removable LED Remote Control Display Panel
Regulated Pure Sine Wave Output
Silent Operation
Compact Size for Easy Installation
USB Port for charging USB devices
|
❖Specifications
Brand | Enerdrive
Model | EN1120S-X
AC Output Power | 2000W
AC Output Current | 8.7A
AC Output Voltage | 230 Vac / 50 Hz
AC Output Waveform | Sinewave (<3% THD)
Nominal DC Input Voltage | 12.5 VDC
No Load battery draw | < 1.5 ADC
DC Input Voltage operating range | 10.5 – 15.5 VDC
Under Voltage Alarm | 11.0 / 12.1 VDC
Under Voltage Alarm Recovery | 11.3 / 12.3 VDC
Under Voltage Shutdown | 10.5 / 11.8 VDC
Under Voltage Shutdown Recovery | 12.0 / 12.6 VDC
Over Voltage Shutdown | 15.5 VDC
USB Port | 5V, 750 mA
AC Transfer Switch
Transfer Time | < 30 ms
Transfer Relay Rating | 16A (resistive load)
AC Input socket IEC-C20 | 16A max
AC Output socket IEC-C19 | 16A max
AC Output Front GPO | 10A max
Safety and Environmental
Conformance | All required Australian Standards , CE LVD: EN/IEC 62040-1,
IEC61558-2-16
EMI / EMC | CE EMC: EN/IEC 62040-2 category C1
Agency Markings | RCM , CE
Operating Temperature | 0°C to 40°C
Storage Temperature | -20°C to 60°C
Relative Humidity | 5-90% non-condensing
Operating Altitude | Up to 3000 meters above sea level
Weights and Dimensions
Weight | 5.9 kg
Dimensions (W x L x H) | 435x230x115 mm
Warranty | 5 Years
